PILOT BOAT

1200 Series
CAPACITY
4 Pilots / 2 Crew
SPEED
35 Knots
POWER
2 x 750 hp
PILOT BOAT

1200 SERIES

Pilot Boat 1200 Series is configured as conventional twin-screw Pilot Boat. The vessel is designed by Camarc for multipurpose operations including ship-assist, pilot transfer duty, crew transport, etc. With a significantly low air draft and a shallow navigational draft, there are few places inaccessible for these Pilot Boats. 1200 Series can be configured for the maximum speed of 35 knots which is a really high performance for a steel hull vessel under 20 meter length.

1200 Series outfitted to high standards in a compact space for crew of up to 4 people. The lower accommodation deck consists of a combined mess and pantry, One quad crew cabins with a shared en-suite. The wheelhouse is designed for maximum all-round visibility from the forward control station, with conventional helm controls.

Download Brochure
Pilot Boats

GALLERY

Image module
GENERAL FEATURES
BASIC FUNCTIONS Pilot, Survey, Crew Transfer, Patrol Duties
CLASSIFICATON BV I • Hull • Mach Coastal Area
SPEED (SERV/MAX) 35.0 knots
CAPACITY 4 Pilots / 2 Crew
DIMENSIONS
LENGTH OVERALL 11,50 m
BEAM OVERALL 3,50 m
DEPTH AT SIDES 1,40 m
DRAFT (DESIGN/MAX) 2,70 m
FUEL OIL CAPACITY
F. WATER CAPACITY
SEWAGE CAPACITY
MACHINERY
MAIN ENGINE Volvo Penta D16
POWER 2x 750 hp @ 1900 rpm
GEARBOX 2x Twindisc 2:1
PROPULSION 900 mm Dia. FP Propellers
AUX. ENGINE 2x 27 kW Single Phase
VENTILATION 24V 14.000 m3/h
AIR CONDITIONING 2x Chilled Water System
EQUIPMENT
GMDSS AREA
NAVIGATION SET
LIFE SAVING
FIRE FIGHTING
PUMPS
ANCHORAGE
WINDLASS
Crew Boat 1700 Series

PROPULSION

Besiktas Workboats

VOLVO PENTA D16

Standart Main propulsion comprises a pair of Volvo Penta D16 Diesel engines each rated 2 x 750hp at 1900 rpm, and each driving fixed pitched 0.86 m diameter propellers on conventional shaft lines.

SERIE 1700 can be customize with different main engines;

CUMMINS QSM11 610hp@2300rpm
VOLVO PENTA D13 600hp@1900rpm
VOLVO PENTA D16 750hp@1900rpm
SCANIA DI16 750hp@1900rpm
VOLVO D13 700hp@2300rpm
MAN D2842 900hp@2100rpm
